Rockford Fosgate M2 500 Watt Mono Amplifier
$349.99
- Description
- Additional information
- Specs
Description
M2 500 Watt Mono Element Ready™ AmplifierM2-500X1
Designed to withstand the elements, the M2-500X1 Element Ready™ amplifier is a 500 watt, class-D model, capable of operating at 4Ω or 2Ω mono. This amplifier is extremely efficient because of its class D technology which reduces demand on the electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases, and integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass. For subwoofers, a variable infrasonic filter and remote level control allows you to tune the bass for the desired level for the music.
The M2 Series were developed for marine audio environments that feature UV resistant protection and special internal conformal coating that protect the electronics from water. It’s designed for those who want a reliable – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of M2 Series amplifiers are also designed to be easy to setup and configure, making them perfect for use in any application.
FEATURES AT A GLANCE
- 2-Year Warranty
- Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
- CEA-2006 Compliant & CE Compliant
- “Auto-Sense” turn-on with remote out (high level in)
- C.L.E.A.N. input/output clip detection and indicator LEDs
- Conformal coated circuit board protects against dust and water
- UV stable powder coated cast aluminum heatsink
- Optimized using AudioGraph PowerCube measurement tool
- Integrated Power and Speaker Terminals
- Balanced Differential Inputs eliminates noise picked up by signal cables
- Integration with OEM and Aftermarket Radios
- Low Impedance Stability
- RATS (Rockford Automated Testing System) proprietary quality & performance tested
- Element Ready™ design protects against outdoor exposure
- Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
- Continuously Variable On Board Punch EQ
- Top Mounted Control Panel
- Short Circuit & Over Current Protection
- Rollback Protection
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- Includes RLC Remote Level Control
- Variable Infrasonic Filter
- Zinc Nickel-plated Marine grade brass connection terminals
- RCA pass-thru outputs
Additional information
| Weight | 15 lbs |
|---|
(Sum of Rated Power)
(RMS Continuous Power)
500 Watts x 1 @ 2Ω
(PVC/PowerCube®)
590 Watts x 1 @ 2Ω
High-Level: 450 mV – 12 V
2Ω: <1.0%
High-Level: 4-Pin Molex
(Pass-Thru active with RCA or Hi-Level input)
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Infrasonic:
15 Hz – 40 Hz @ 12dB/Octave Butterworth
C.L.E.A.N. In
C.L.E.A.N. Out
(not included)
(4.9 cm x 17.3 cm x 21.5 cm)
